The Next Generation

Formula Mazda


GraphicCarAssy - 20191002 NewWings,Top,WhiteBG,0.20.png

Formula Mazda FMzR

Championship Driver Advancement Award

The Champion may select from one of the following:

-$100,000 – Cooper Tires USF2000 Championship*

-$65,000 – Global MX-5 Cup Championship*

-$50,000 – F4 U.S. Championship*

-$35,000 – to use toward defending your championship in Formula Mazda FMzR

*toward full season commitment



FOR MORE INFORMATION

If you are interested in receiving detailed information regarding the championship as it becomes available. Sign up to join our bulletins.



Bodywork
& Aero

• Fiberglass Indy Style Body
• Kevlar infused, side intrusion, exterior side skins
• Adjustable Single Plane Aluminum Front Wing
• Adjustable Single Plane Aluminum Rear Wing


Chassis

• 1018/1020/DOM steel-tube frame with integral roll cage structure constructed with TIG and MIG welding
• Kevlar interior side panels
• Hans compliant head surround
• Carbon Kevlar integrated seat available


Engine

• Mazda Developed 2-liter MZR (sealed), four-cylinder engine with dry sumped oiling system
• Fuel Injected
• Managed by encrypted ECU


Suspension

• Double A-arm suspension
• Pushrod actuated Penske
• Eibach springs
• Chassis adjustments limited to ride height, camber, toe, and anti roll bar


Gearbox

• SADEV SL82 six-speed transmission (+reverse) sequential gearbox fitted with optimized Formula Mazda specific gear ratio


Wheels

• OZ Racing one-piece aluminum wheels
• 13 x 8 front
• 13 x 10 rear


Tires

• Goodyear race tires built to Formula Mazda specification
• Dry and wet compounds available


Data Acquisition

• AiM dash with data logging
• GPS based


Brakes

• 4 piston caliper with vented discs on front and rear axles
• In-cockpit driver adjustable brake bias


Safety System

• SFI 6 point safety Harness
• SFI fire extinguisher system
